PADDE ES200 Series Electric Strike – 12VDC, Fire Rated

The PADDE ES200 electric strike is designed for high-security access control on hinged doors, including fire-rated applications. It features a stainless steel striker, deep throat design, and field-selectable fail-safe or fail-secure modes.

• Fire rated up to 4 hours

• Field-selectable fail-safe or fail-secure operation

• High holding force: 850kg

• Low current draw: Max 175mA @ 12VDC

• Suits hinged doors with fire or security needs

• Deeper throat than standard electric strikes

• Stainless steel striker with 3 hardened locking pins

• Power to lock or power to open (configurable)

• Solenoid can be continuously powered

• Pre-drilled for lip extension

• Includes mounting kit and self-adhesive template

Specifications:
Brand: PADDE
Model: ES200 Series
Voltage: 12VDC
Current: 175mA @ 12VDC
Fire Rated: Yes (up to 4 hours)
Locking Mode: Fail Safe / Fail Secure (reversible)
Holding Force: 850kg
Drilled for Lip Extension: Yes
Body Depth: 27 mm
Material: Stainless steel striker
