PADDE ES200 Series Electric Strike – 24VDC, Fire Rated

The PADDE ES200 electric strike is engineered for high-security hinged doors, including fire-rated applications. It features a stainless steel striker, deeper throat design, and field-selectable fail-safe or fail-secure modes for flexible installation.

• Fire rated up to 4 hours

• Field-changeable fail-safe/fail-secure operation

• Holding force of 850kg

• Low current consumption: 88mA @ 24VDC

• Suitable for hinged doors with fire or security needs

• Deeper throat for better latch engagement

• Power to lock or power to open (configurable)

• Solenoid supports continuous power

• Pre-drilled for lip extension

• Includes mounting kit and self-adhesive installation template

Specifications:
Brand: PADDE
Model: ES200 Series
Voltage: 24VDC
Current: 88mA @ 24VDC
Fire Rated: Yes (4 hours)
Locking Mode: Fail Safe / Fail Secure (field changeable)
Holding Force: 850kg
Body Depth: 27 mm
Material: Stainless steel striker
