PADDE ES9000 Electric Strike – 10–30VDC, SCEC SL3 Approved, Fire Rated

The PADDE ES9000 Electric Strike is a high-security solution designed for demanding access control environments. Built from solid stainless steel and manufactured in Melbourne, it is Australian Government listed, SCEC endorsed for Security Level 3, and fire rated for up to 4 hours.

• SCEC endorsed for SL3 (Medium Threat Level) areas

• Fire rated up to 4 hours (when used with approved door set)

• Operates under pre-load conditions up to 25kg

• Field-selectable fail-safe or fail-secure mode

• Fully monitored: strike locked and door closed status

• Stainless steel striker with 3 hardened locking pins

• Equipped with silencer pad for quieter operation

• Power to open or power to lock (configurable)

• Solenoid monitor: 1A NO/NC microswitch

• Door/latch monitor: 1A NO/NC microswitch

• Continuous power-rated solenoid with built-in polarity and back EMF protection

• Multi-voltage: 10VDC to 30VDC (250mA @ 12VDC / 130mA @ 24VDC)

• Static strength: 680kg

• Endurance tested to 200,000 cycles at 25kg pre-load

• IP54 weather resistant

• Supplied with self-adhesive installation template

• Suitable for 15mm latch bolt with 3mm door gap

Specifications:
Brand: PADDE
Model: ES9000
Voltage: 10–30VDC
Current: 250mA @ 12VDC, 130mA @ 24VDC
Monitoring: Yes (Strike, Solenoid, Door)
Holding Strength: 680kg
Fire Rated: Yes (4 hours)
SCEC Endorsed: Yes – SL3 with approved keying system

Pre-load Tolerance: Up to 25kg
Locking Mode: Fail Safe / Fail Secure (field selectable)
IP Rating: IP54
Material: Solid Stainless Steel
